Volvo S80 II facelift (2009-2013) fuse compartment distribution box Wiring diagram
This page shows the only wiring diagram for the component.fuse compartment distribution box, which is found in the car Volvo S80 II facelift (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse compartment distribution box (1 of 1)
1 74/523
13 15 16 17 74/519
5 10 11 12 74/309
BLK/BLU WIRE
BLK/GRN WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
COMPUTER DATA LINES SYSTEM
FRONT PARKING ASSISTANCE SENSOR (LF/I)
FRONT PARKING ASSISTANCE SENSOR (LF/O)
FRONT PARKING ASSISTANCE SENSOR (RF/I)
FRONT PARKING ASSISTANCE SENSOR (RF/O)
FUSE COMPARTMENT DISTRIBUTION BOX
GRN/WHT WIRE
GRY/ORG WIRE
HOT W/ 15 FEED RELAY ENERGIZED
PARKING ASSISTANCE MODULE (PAM) (RIGHT REAR OF LUGGAGE COMPT)
PASSENGER
REAR PARKING ASSISTANCE SENSOR (LR/I)
REAR PARKING ASSISTANCE SENSOR (RR/I)
REAR PARKING REAR PARKING ASSISTANCE ASSISTANCE SENSOR (RR/O) SENSOR (LR/O)
VIO/GRY WIRE
VIO/ORG WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Parking assistant circuit -> FUSE COMPARTMENT DISTRIBUTION BOX
