Rear heated seats circuit, without massage for Volvo S80 II facelift 2 (2013-2016)
Rear heated seats circuit, without massage
74/403
BLK WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLU WIRE
BLU/RED WIRE
BRN/VIO WIRE
CENTRAL ELECTRONIC MODULE (CEM) (BEHIND RIGHT END OF
COMPUTER DATA LINES SYSTEM
DASH)
FUSE
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/VIO WIRE
HOT W/ 15 FEED REAR RELAY ENERGIZED
HOT W/ 15 FEED RELAY ENERGIZED
LEFT REAR SEAT BACKREST HEATING ELEMENT
LEFT REAR SEAT CUSHION HEATING ELEMENT
LEFT REAR SEAT HEATER CONTROL MODULE (UNDER LEFT REAR SEAT)
LEFT REAR SEAT TEMPERATURE SENSOR (IN LEFT REAR SEAT BOTTOM)
REAR HEATED SEATS SWITCH
RED WIRE
RIGHT REAR SEAT BACKREST HEATING ELEMENT
RIGHT REAR SEAT CUSHION HEATING ELEMENT
RIGHT REAR SEAT HEATER CONTROL MODULE (UNDER RIGHT REAR SEAT)
RIGHT REAR SEAT TEMPERATURE SENSOR (IN RIGHT REAR SEAT BOTTOM)
VIO/GRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
