Volvo S80 II (2006-2010) steering wheel angle sensor module steering angle sensor wiring diagram
This page shows the only wiring diagram for the component.steering wheel angle sensor module steering angle sensor, which is found in the car Volvo S80 II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
steering wheel angle sensor module steering angle sensor wiring diagram (1 of 1)
15- FEED RELAY
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/ORG WIRE
CENTRAL ELECTRONIC MODULE
CENTRAL ELECTRONIC MODULE (BEHIND RIGHT END OF DASH)
COMPUTER DATA LINES SYSTEM
FUSE
FUSE FUSE
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/YEL WIRE
HEADLAMP CONTROL MODULE (HCM) (RIGHT REAR OF ENGINE COMPARTMENT)
HOT AT ALL TIMES
LEFT FRONT LAMP HOUSING
NCA WIRE
ORG/ WIRE
RED WIRE
RED/BLU WIRE
RIGHT FRONT LAMP HOUSING
RIGHT FRONT SUSPENSION HEIGHT SENSOR (W/ FOUR-C) (IN RIGHT FRONT WHEELWELL)
RIGHT FRONT SUSPENSION HEIGHT SENSOR (W/O FOUR-C) (IN RIGHT FRONT WHEELWELL)
RIGHT REAR SUSPENSION HEIGHT SENSOR (W/ FOUR-C) (IN RIGHT REAR WHEELWELL)
RIGHT REAR SUSPENSION HEIGHT SENSOR (W/O FOUR-C) (IN RIGHT REAR WHEELWELL)
SOLAR SENSOR, TWILIGHT SENSOR, INDICATOR ALARM (TOP CENTER OF DASH)
STEERING WHEEL ANGLE SENSOR MODULE STEERING ANGLE SENSOR
SUSPENSION MODULE (SUM) (BEHIND CENTER OF REAR SEATS)
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Headlamp beam adjustment circuit, with active headlights -> STEERING WHEEL ANGLE SENSOR MODULE STEERING ANGLE SENSOR
