Volvo S70 I (1997-2000) passenger module generator Wiring diagram
This page shows the only wiring diagram for the component.passenger module generator, which is found in the car Volvo S70 I (1997-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger module generator (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CONTACT REEL (TOP OF STEERING COLUMN)
DATA LINK CONNECTOR (ON CENTER CONSOLE, NEAR SHIFT LEVER)
GRN WIRE
GRN/BRN WIRE
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT CLUSTER
LEFT SIDE SEAT BELT TENSIONER IGNITER
NCA WIRE
OFF
ORG/ WIRE
PASSENGER MODULE GENERATOR
PNK WIRE
RED WIRE
RED/WHT WIRE
RIGHT SIDE SEAT BELT TENSIONER IGNITER
RUN WIRE
SRS CRASH SENSOR (IN CENTER FLOOR CONSOLE)
SRS SAFETY CIRCUIT
SRS WARNING INDICATOR
STEERING WHEEL MODULE
VIO WIRE
WHT WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraint circuit, except convertible -> PASSENGER MODULE GENERATOR
