Volvo S70 I (1997-2000) overload relay 106 Wiring diagrams
This page contains all the electrical diagrams for the component. overload relay 106, in which he is found in the car Volvo S70 I (1997-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
overload relay 106 wiring diagram (1 of 2)
31/12
31/15
31/32
31/33
31/4
31/44
31/47
31/48 (LEFT SIDE OF ENG)
31/50
31/51
31/52 LEFT SIDE VANITY MIRROR LAMP
31/55
31/65
A/C CONTROL PANEL
ABS CONTROL MODULE
ACCESSORY CONNECTOR
AIR PREHEATING PTC RESISTOR
ALARM HORN
ALARM SYSTEM
ALARM/ELECTRONIC IMMOBILIZER INDICATOR
AMPLIFIER
ANTENNA INHIBITOR RELAY
AW 50-42 MODE SELECTOR
AW 50-42 TRANSMISSION CONTROL MODULE
BATTERY
BLK WIRE
BLOWER FAN
BLOWER FAN POWER UNIT
BLU WIRE
BONNET ALARM SWITCH
BRAKE FLUID LEVEL SWITCH
CABIN TEMPER- ATURE SENSOR
CAR TILT SENSOR
CD CHANGER
CENTRAL ELECTRICAL UNIT (LEFT REAR OF ENG COMPT)
CENTRAL LOCKING MOTOR
CENTRAL LOCKING/ ALARM REMOTE CONTROL UNIT
CENTRAL LOCKING/ ANTI-THEFT ALARM CONTROL MODULE
CRUISE CONTROL MODULE
DATA LINK CONNECTOR
DATA LINLK CONNECTOR
ELECTRONIC CLIMATE CONTROL MODULE
ELECTRONIC STARTER INHIBITOR
ENGINE CONTROL MODULE
ENGINE COOLANT FAN PARKING BRAKE SWITCH
ENGINE COOLANT LEVEL SWITCH
FRONT ASHTRAY ILLUMINATION LAMP
FRONT CIGARETTE LIGHTER
FRONT FOG LIGHT SWITCH
FRONT WASHER MOTOR
FUEL PUMP RELAY
GEAR SELECTOR ILLUMINATION LAMP
GLASS BREAKAGE SENSOR
GLOVE BOX LAMP 1/1-
HAZARD/ FLASHER RELAY SWITCH
HIGHMOUNT STOP LAMP
HIGHMOUNT STOP LAMP RIGHT REAR BACKREST BASS SPEAKER FILTER
IGNITION CHARGE MODULE/IGNITION COIL
INSTRUMENT CLUSTER
INTAKE AIR TEMPERATURE SENSOR RIGHT REAR SEAT HEATER PAD
INTERMITTENT TAILGATE WIPER RELAY
LEFT DOOR SILL HARNESS CONNECTOR (LEFT SEAT) HIGHMOUNT STOP LAMP
LEFT FRONT DOOR LOCK
LEFT FRONT FOG LAMP
LEFT FRONT HEATED SEAT SWITCH
LEFT FRONT LAMP UNIT
LEFT FRONT PARK/TURN LAMP
LEFT FRONT POWER WINDOW SWITCH
LEFT FRONT SEAT BELT SWITCH
LEFT FRONT SEAT HEATED RELAY
LEFT FRONT STRUT TOWER)
LEFT HEADLAMP WIPER MOTOR
LEFT LICENSE PLATE LAMP
LEFT LOWER TAILLAMP ASSEMBLY
LEFT MOVEMENT DETECTOR
LEFT POWER DOOR MIRROR
LEFT POWER WINDOW RELAY
LEFT REAR BACKREST BASS SPEAKER FILTER
LEFT REAR LOCK UNIT LEFT FRONT SEAT CONTROL MODULE
LEFT REAR POWER WINDOW SWITCH RIGHT REAR POWER WINDOW SWITCH
LEFT REAR READING LAMP
LEFT REAR SEAT HEATER PAD FUEL PUMP
LEFT SIDE TURN SIGNAL FLASHER
LEFT TAILLAMP UNIT
LEFT UPPER TAILLAMP ASSEMBLY
LEFT VANITY LAMP
LICENSE PLATE LAMP
LIGHT SWITCH
MAIN HEADLIGHT RELAY/BULB FAILURE WARNING SENSOR
MOVEMENT DETECTOR
NCA WIRE
OVERHEAD CONSOLE
OVERLOAD RELAY 105
OVERLOAD RELAY 106
POWER ANTENNA
POWER DOOR MIRRORS SWITCH
POWER GROUND CONNECTOR
POWER SUNROOF CONTROL MODULE
POWER SUNROOF SWITCH
POWER WINDOW SWITCH
POWER WINDOWS CONTROL MODULE
PULSE SECONDARY AIR INJECTION SYSTEM PUMP
RADIO
REAR BULB FAILURE WARNING SENSOR
REAR CIGARETTE LIGHTER
REAR FOG LIGHT SWITCH 31/7
REAR SEAT HEATED RELAY
REAR SEAT HEATED SWITCH
REAR VIEW MIRROR)
REAR WINDOW HEATED ELEMENT
REAR WINDOW/ DOOR MIRROR HEATED RELAY
REAR WINDOW/ DOOR MIRROR HEATED SWITCH
RIGHT FRONT DOOR LOCK
RIGHT FRONT FOG LAMP
RIGHT FRONT HEATED SEAT SWITCH
RIGHT FRONT LAMP UNIT
RIGHT FRONT PARK LAMP/ TURN SIGNAL LAMP
RIGHT FRONT POWER WINDOW SWITCH
RIGHT FRONT SEAT CONTROL MODULE RIGHT DOOR SILL HARNESS CONNECTOR (RIGHT SEAT)
RIGHT FRONT SEAT HEATED RELAY
RIGHT HEADLAMP WIPER MOTOR
RIGHT LICENSE PLATE LAMP
RIGHT LOWER TAILLAMP ASSEMBLY
RIGHT MOVEMENT DETECTOR
RIGHT POWER DOOR MIRROR
RIGHT POWER WINDOW RELAY
RIGHT REAR DOOR LOCK UNIT REAR WINDOW HEATING ELEMENT
RIGHT REAR READING LAMP
RIGHT SIDE TURN SIGNAL LAMP
RIGHT SIDE VANITY MIRROR LAMP
RIGHT TAILAMP UNIT
RIGHT TAILLAMP UNIT
RIGHT UPPER TAILLAMP ASSEMBLY
ROLL BAR CONTROL MODULE
RTI CONTROL MODULE
RTI DISPLAY RTI CD-PLAYER
SEAT BELT REMINDER/ KEY WARNING RELAY
SHIFT LOCK SOLENOID
SIGNAL GROUND CONNECTOR
SOFT TOP CONTROL MODULE
SOFT TOP SWITCH
SOFT-TOP ACKNOWLEDGMENT SIGNAL SPEAKER
TAILGATE LOCK UNIT
TAILGATE LOCKING UNIT
TAILGATE WIPE/WASHER SWITCH
TAILGATE WIPER MOTOR
THROTTLE MECHANISM KICK DOWN SWITCH
TRACS SWITCH
TRAILER CONNECTOR
TRUNK LID/ FUEL TANK COVER SWITCH
TRUNK LID/ OPENING RELAY
WASHER FLUID LEVEL SENSOR
WHT WIRE
WINDSHIELD INTERMITTENT WIPER RELAY
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit -> OVERLOAD RELAY 106
overload relay 106 wiring diagram (2 of 2)
A/C CONTRL PANEL
ACCESSORY CONNECTOR
BLK WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN/ORG WIRE
CENTRAL ELECTRICAL UNIT (LEFT REAR OF ENG COMPT)
CENTRAL ELECTRICAL UNIT (LEFT REAR OF ENGINE COMPT)
ENGINE CONTROL MODULE
FROM
FROM CIRCUIT
FROM FUSE
FRONT CIGAR LIGHTER
FUSE
FUSE FUSE
GRN/YEL WIRE
GRY/RED WIRE
HEATED REAR WINDOW/DOOR MIRRORS RELAY
IGNITION SWITCH
KEY IN
KEY-IN IGNITION SWITCH
LEFT FRONT HEATED REAR RELAY
LEFT FRONT SEAT CONTROL MODULE
LEFT FRONT STRUT TOWER)
LIGHT SWITCH
NCA WIRE
OFF
ONLY
ORG/ WIRE
OVERLOAD RELAY 105 (X+)
OVERLOAD RELAY 106
POWER GROUND CONNECTOR
RADIO TAILGATE WIPER/ WASHER SWITCH TAILGATE WIPER MOTOR
REAR CIGAR LIGHTER
REAR HEATED SEAT RELAY, REAR HEATED SEAT SWITCH RIGHT FRONT HEATED REAR RELAY
RED WIRE
RED/BLK WIRE
ROLL BAR CONTROL MODULE
RTI CONTROL MODULE, RTI DISPLAY, RTI CD-PLAYER
SOFT TOP CONTROL MODULE
SRS CRASH SENSOR
SRS SENSOR UNIT
STARTER MOTOR RELAY, SERVICE SOCKET
TAILGATE WIPER INTER- MITTENT REALY
WINSHIELD WIPER INTERMITTENT RELAY, FRONT WASHER MOTOR WINDSHIELD WIPER MOTOR
X-RAIL CONNECTOR FUSE
YEL WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Power distribution circuit (3 of 3) -> OVERLOAD RELAY 106
