Headlamp washer circuit for Volvo S60 II facelift (2013-2018)
Headlamp washer circuit
15- FEED RELAY
BLK WIRE
BLK/ORG WIRE
BLU/BLK WIRE
CENTRAL ELECTRONIC MODULE
CENTRAL ELECTRONIC MODULE (RIGHT END OF DASH)
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION MODULE
ENGINE COMPARTMENT DISTRIBUTION BOX
GRN/BLK WIRE
GRN/WHT WIRE
GRY/ORG WIRE
HEADLIGHT HIGH PRESSURE WASHER MOTOR
HEADLIGHT WASHER MOTOR RELAY
HORN RELAY
HOT AT ALL TIMES
LEFT STEERING WHEEL SWITCH
NCA WIRE
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RIGHT STEERING WHEEL SWITCH
STEERING WHEEL MODULE
VIO WIRE
VIO/ORG WIRE
WASHER FLUID LEVEL SENSOR
WIPER
YEL/GRN WIRE
