Tire pressure monitoring circuit for Volvo S60 II facelift (2013-2018)
Tire pressure monitoring circuit
4/119
BLK/BLU WIRE
BLK/WHT WIRE
CEM
CENTRAL ELECTRONIC MODULE (CEM)
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION MODULE (DIM)
ENGINE COMPARTMENT COLD ZONE DISTRIBUTION BOX
ENGINE COMPARTMENT DISTRIBUTION BOX
GRN/RED WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
KEYLESS VEHICLE MODULE
LEFT FRONT TIRE PRESSURE SENSOR
LEFT REAR TIRE PRESSURE SENSOR
PASSENGER COMPARTMENT DISTRIBUTION BOX
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
REMOTE KEYLESS ENTRY (RKE)
REMOTE RECEIVER MODULE (RRX)
RIGHT END OF DASH)
RIGHT FRONT TIRE PRESSURE SENSOR
RIGHT REAR TIRE PRESSURE SENSOR
VIO/ORG WIRE
W/O KEYLESS ENTRY
W/O START/STOP FUNCTION W/ START/STOP FUNCTION
