Rear heated seats circuit for Volvo S60 II facelift (2013-2018)
Rear heated seats circuit
74/403
BLK WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLU WIRE
BLU/RED WIRE
BRN/VIO WIRE
CENTRAL ELECTRONIC MODULE (CEM)
COMPUTER DATA LINES SYSTEM
ENGINE COMPARTMENT DISTRIBUTION BOX
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/VIO WIRE
HOT W/ 15 FEED REAR RELAY ENERGIZED
HOT W/ 15 FEED RELAY ENERGIZED
LEFT REAR SEAT BACKREST HEATING ELEMENT
LEFT REAR SEAT CUSHION HEATING ELEMENT
LEFT REAR SEAT HEATER CONTROL MODULE
LEFT REAR SEAT TEMPERATURE SENSOR
ORG/ WIRE
PASSENGER COMPARTMENT DISTRIBUTION BOX
REAR HEATED SEAT SWITCH
RED WIRE
RIGHT END OF DASH)
RIGHT REAR SEAT BACKREST HEATING ELEMENT
RIGHT REAR SEAT CUSHION HEATING ELEMENT
RIGHT REAR SEAT HEATER CONTROL MODULE
RIGHT REAR SEAT TEMPERATURE SENSOR
VIO WIRE
VIO/GRN WIRE
WHT WIRE
WHT/GRN WIRE
WHT/ORG WIRE
