Instrument cluster circuit for Volvo S60 II facelift (2013-2018)
Instrument cluster circuit
2.0L TURBO 3.0L TURBO, 2.5L TURBO
74/301
74/511
BLK WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRAKE FLUID LEVEL SENSOR
CENTRAL ELECTRONIC MODULE
CENTRAL ELECTRONIC MODULE (CEM)
COMPUTER DATA LINES SYSTEM
COOLANT LEVEL SENSOR
DRIVER INFORMATION MODULE (DIM)
EJECTOR SIDE FUEL LEVEL SENSOR
ENGINE CONTROL MODULE (ECM)
FUEL PUMP
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
PARK BRAKE MODULE
PARKING BRAKE SWITCH
PUMP SIDE FUEL LEVEL SENSOR
RED/WHT WIRE
RIGHT END OF DASH)
TRANSMISSION CONTROL MODULE (TCM)
VIO/BRN WIRE
VIO/ORG WIRE
YEL/VIO WIRE
