Headlamp beam adjustment circuit for Volvo S60 II facelift (2013-2018)
Headlamp beam adjustment circuit
15- FEED RELAY
74/512
74/513
74/519
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN/BLU WIRE
CENTRAL ELECTRONIC MODULE (CEM)
CENTRAL ELECTRONIC MODULE (CEM) (RIGHT END OF DASH)
COMPUTER DATA LINES SYSTEM
ELECTRONIC SUSPENSION SYSTEM
ENGINE COMPARTMENT DISTRIBUTION BOX
GRN/BLK WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT FRONT LAMP HOUSING
LEFT HEADLIGHT LEVEL ADJUSTMENT MOTOR
RED/BLK WIRE
RED/BLU WIRE
RIGHT FRONT LAMP HOUSING
RIGHT FRONT SUSPENSION HEIGHT SENSOR
RIGHT HEADLIGHT LEVEL ADJUSTMENT MOTOR
RIGHT REAR SUSPENSION HEIGHT SENSOR
SOLAR SENSOR, TWILIGHT SENSOR, INDICATOR ALARM
STEERING WHEEL ANGLE SENSOR MODULE
STEERING WHEEL MODULE (SWM)
SUSPENSION MODULE (SUM)
YEL WIRE
YEL/GRN WIRE
