Trailer tow circuit, 7-pin for Volvo S60 II facelift (2013-2018)
Trailer tow circuit, 7-pin
7-PIN TOW HITCH CABLE HARNESS
BLK WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLU WIRE
BRAKE LIGHT CONTACT
BRN WIRE
CARGO COMPARTMENT DISTRIBUTION BOX
CENTRAL ELECTRONIC MODULE CENTRAL ELECTRONIC MODULE
COMPUTER DATA LINES SYSTEM
ELECTRICAL BRAKE CONTROLLER
ENGINE COMPARTMENT COLD ZONE
ENGINE COMPARTMENT DISTRIBUTION BOX
G-TRM
GRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
LEFT REAR LAMP HOUSING
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT END OF DASH)
STOP
TRAILER MODULE (TRM)
VIO/BRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/O START/STOP FUNCTION W/ START/STOP FUNCTION
WHT WIRE
YEL WIRE
