Volvo S60 II facelift (2013-2018) right blind spot detection indicator Wiring diagram
This page shows the only wiring diagram for the component.right blind spot detection indicator, which is found in the car Volvo S60 II facelift (2013-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right blind spot detection indicator (1 of 1)
15- FEED RELAY
74/507
74/508
74/526
BLK/BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BRN WIRE
BRN WIRE
CEM
CENTRAL ELECTRONIC MODULE (CEM)
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM)
ENGINE COMPARTMENT COLD ZONE
ENGINE COMPARTMENT DISTRIBUTION BOX
GRN/WHT WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
LEFT BLIND SPOT DETECTION INDICATOR
LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SODL)
PASSENGER COMPARTMENT DISTRIBUTION BOX
PASSENGER DOOR MODULE (PDM)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRY WIRE
RIGHT BLIND SPOT DETECTION INDICATOR
RIGHT END OF DASH)
RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SODR)
VIO/GRN WIRE
VIO/ORG WIRE
VIO/RED WIRE
W/ START/STOP FUNCTION
W/O START/STOP FUNCTION
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Blind spot information system circuit -> RIGHT BLIND SPOT DETECTION INDICATOR
