Volvo S60 II facelift (2013-2018) nca Wiring diagrams

This page contains all the electrical diagrams for the component. nca, in which he is found in the car Volvo S60 II facelift (2013-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram nca (21 of 38)

Wiring diagram nca for Volvo S60 II facelift (2013-2018) (21 of 38)
Get lifetime access to Volvo S60 II facelift (2013-2018)

2.0L TURBO 3.0L TURBO 3.0L TURBO 2.5L TURBO, 2.0L TURBO 3.0L TURBO, 2.5L TURBO 2.0L TURBO 74/301 74/321 74/403 74/411 74/412 74/504 74/511 74/512 ACCELERATOR PEDAL SENSOR BLK WIRE BLK/ORG WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BRAKE CONTROL MODULE (LEFT REAR OF ENGINE COMPT) BRAKE LIGHT CONTACT BRAKE LIGHT DIAGNOSTIC CONTACT BRAKE PEDAL SENSOR (W/ ADAPTIVE CRUISE CONTROL) BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/VIO WIRE CEM CENTRAL ELECTRONIC MODULE COMPUTER DATA LINES SYSTEM DRIVER INFORMATION MODULE (DIM) DSTC ACTIVATION UNIT ENGINE COMPARTMENT DISTRIBUTION BOX ENGINE CONTROL MODULE ENGINE MANAGEMENT SYSTEM MAIN RELAY FORWARD SENSING MODULE FORWARD-AIMED RADAR GEAR SELECTOR MODULE (GSM) GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT W/ 15 FEED RELAY ENERGIZED LEFT FRONT ABS SENSOR LEFT REAR ABS SENSOR LEFT STEERING WHEEL SWITCH NCA WIRE RED/VIO WIRE RED/WHT WIRE RIGHT END OF DASH) RIGHT FRONT ABS SENSOR RIGHT REAR ABS SENSOR RIGHT STEERING WHEEL SWITCH STEERING WHEEL MODULE (SWM) THROTTLE UNIT (ON THROTTLE ASSEMBLY) TRANSMISSION CONTROL MODULE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/RED WIRE VIO/WHT WIRE W/ ADAPTIVE CRUISE CONTROL WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component -> Cruise control circuit -> NCA WIRE

Wiring diagram nca (22 of 38)

Wiring diagram nca for Volvo S60 II facelift (2013-2018) (22 of 38)
Get lifetime access to Volvo S60 II facelift (2013-2018)

74/30 74/31 BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/VIO WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/VIO WIRE CLIMATE CONTROL MODULE (CCM) COMPUTER DATA LINES SYSTEM DRIVER'S SEAT BACKREST HEATING ELEMENT DRIVER'S SEAT CUSHION HEATING ELEMENT DRIVER'S SEAT TEMPERATURE SENSOR DRIVER'S SIDE SEAT HEATING MODULE (SHM) GRN WIRE GRN/BLK WIRE GRY WIRE GRY/ORG WIRE HOT W/ 15 FEED REAR RELAY ENERGIZED NCA WIRE PASSENGER COMPARTMENT DISTRIBUTION BOX PASSENGER SEAT BACKREST HEATING ELEMENT PASSENGER SEAT CUSHION HEATING ELEMENT PASSENGER SEAT TEMPERATURE SENSOR PASSENGER SIDE SEAT HEATING MODULE (SHM) RED/BLK WIRE RIGHT END OF DASH) SEAT FAN VIO/ORG WIRE WHT/GRN WIRE YEL WIRE YEL/RED WIRE

Go to component -> Front heated seats circuit, w/ fans -> NCA WIRE

Wiring diagram nca (23 of 38)

Wiring diagram nca for Volvo S60 II facelift (2013-2018) (23 of 38)
Get lifetime access to Volvo S60 II facelift (2013-2018)

74/411 BLK WIRE BLU WIRE BLU/BLK WIRE CEM CENTRAL ELECTRONIC MODULE COMPUTER DATA LINES SYSTEM ENGINE COMPARTMENT COLD ZONE ENGINE COMPARTMENT DISTRIBUTION BOX GRN WIRE GRN/BLK WIRE GRY WIRE HEATED STEERING WHEEL HEATED STEERING WHEEL MODULE (HSWM) HOT AT ALL TIMES NCA WIRE ORG/ WIRE RED WIRE RIGHT END OF DASH) STEERING WHEEL MODULE (SWM) (TOP OF STEERING COLUMN) TEMPERATURE SENSOR VIO WIRE W/ START/STOP FUNCTION W/O START/STOP FUNCTION YEL WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/RED WIRE

Go to component -> Heated steering wheel circuit -> NCA WIRE

Wiring diagram nca (24 of 38)

Wiring diagram nca for Volvo S60 II facelift (2013-2018) (24 of 38)
Get lifetime access to Volvo S60 II facelift (2013-2018)

4 74/534 74/403 74/409 74/421 74/430 AUXILIARY INPUT (AUX) BLK WIRE BLK/GRY WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE GRN WIRE HOT AT ALL TIMES IAM IHU MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE PASSENGER COMPARTMENT DISTRIBUTION BOX RED WIRE RED/BLK WIRE RIGHT END OF DASH) RSE CONTROL MODULE TV ANTENNA TV ANTENNA (TOP OF LEFT "D" PILLAR) TV RECEIVER VIO WIRE VIO/RED WIRE W/ REAR SEAT ENTERTAINMENT W/ SENSUS CONNECTED TOUCH W/ TVM W/O REAR SEAT ENTERTAINMENT W/O SENSUS CONNECTED TOUCH WHT WIRE WINDOW ANTENNA AMPLIFIER 2 YEL WIRE YEL/RED WIRE

Go to component -> Radio circuit, base (1 of 3) -> NCA WIRE

Wiring diagram nca (25 of 38)

Wiring diagram nca for Volvo S60 II facelift (2013-2018) (25 of 38)
Get lifetime access to Volvo S60 II facelift (2013-2018)

74/409 74/508 ACCESSORY CONNECTIVITY UNIT (ACU) AUX 2 L- AUX 2 R- BLK WIRE BLK/GRY WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DATA GPS ANT GPS ANTENNA GRN WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY/ORG WIRE IAM W/ SENSES CONNECTED TOUCH IMU INFOTAINMENT CONTROL MODULE (ICM) INFOTAINMENT HEAD UNIT (IHU) INFOTAINMENT SOFTWARE DOWNLOAD USB-PORT LIN LVDS MIC SCREN MIC SIG MICROPHONE MOST DATA BUS CIRCUIT NAVIGATION SYSTEM NCA WIRE ORG/ WIRE POWER RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT FRONT TWEETER SHIELD V-BUS VBUS VIO WIRE VIO/BLK WIRE VIO/ORG WIRE VIO/RED WIRE W/ SENSUS CONNECTED TOUCH W/O SENSES CONNECTED TOUCH WHT WIRE YEL/BLK WIRE YEL/RED WIRE

Go to component -> Radio circuit, base (3 of 3) -> NCA WIRE

Wiring diagram nca (26 of 38)

Wiring diagram nca for Volvo S60 II facelift (2013-2018) (26 of 38)
Get lifetime access to Volvo S60 II facelift (2013-2018)

4 74/534 74/403 74/405 74/409 74/412 74/419 74/420 74/421 74/430 74/602 74/607 74/608 ACCESSORIES USB-PORT AM/FM OUT AUXILIARY INPUT (AUX) BLK WIRE BLK/GRY WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE DATA FEED GRN WIRE GRN/BRN WIRE GRN/VIO WIRE GRN/WHT WIRE GSM/GPS/RDAR ANTENNA HOT AT ALL TIMES INTEGRATED AUDIO MODULE (IAM) MICROPHONE MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE PASSENGER COMPARTMENT DISTRIBUTION BOX RED WIRE RED/BLK WIRE RIGHT END OF DASH) RSE CONTROL MODULE SHIELD TV RECEIVER (TVM) V-BUS VICS ANTENNA (BASE OF LEFT "A" PILLAR) VIO WIRE VIO/RED WIRE W/ REAR SEAT ENTERTAINMENT W/ SENSUS CONNECTED TOUCH W/ TVM W/O REAR SEAT ENTERTAINMENT W/O SENSUS CONNECTED TOUCH WHT WIRE WINDOW ANTENNA AMPLIFIER WINDOW ANTENNA AMPLIFIER 1 YEL WIRE YEL/RED WIRE

Go to component -> Radio circuit, premium iam (2 of 3) -> NCA WIRE

Wiring diagram nca (27 of 38)

Wiring diagram nca for Volvo S60 II facelift (2013-2018) (27 of 38)
Get lifetime access to Volvo S60 II facelift (2013-2018)

74/409 ACCESSORY CONNECTIVITY UNIT (ACU) AUX 2 L- AUX 2 R- BLK WIRE BLK/GRY WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DATA GPS ANT GPS ANTENNA GRN WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY/ORG WIRE INFOTAINMENT CONTROL MODULE (ICM) LIN LVDS MIC SCREN MIC SIG MICROPHONE MOST DATA BUS CIRCUIT NAVIGATION SYSTEM NCA WIRE ORG/ WIRE POWER RED WIRE SHIELD TV ANTENNA TV ANTENNA (TOP OF LEFT "D" PILLAR) VBUS VIO WIRE VIO/ORG WIRE VIO/RED WIRE W/ SENSUS CONNECTED TOUCH W/O SENSUS CONNECTED TOUCH WHT WIRE WINDOW ANTENNA AMPLIFIER 2 YEL/RED WIRE

Go to component -> Radio circuit, premium iam (3 of 3) -> NCA WIRE

Wiring diagram nca (28 of 38)

Wiring diagram nca for Volvo S60 II facelift (2013-2018) (28 of 38)
Get lifetime access to Volvo S60 II facelift (2013-2018)

74/403 74/405 74/409 74/412 74/419 74/420 74/602 74/607 74/608 AM/FM OUT AUXILIARY INPUT (AUX) BLK WIRE BLK/GRY WIRE BRN WIRE BRN/WHT WIRE CENTER CONSOLE DISPLAY COMPUTER DATA LINES SYSTEM DATA FEED GRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRY/ORG WIRE GSM/GPS/RDAR ANTENNA INFOTAINMENT HEAD UNIT (IHU) MICROPHONE NCA WIRE ORG/ WIRE RED WIRE RSE CONTROL MODULE SHIELD USB PORT V-BUS VIO WIRE VIO/ORG WIRE VIO/RED WIRE W/ RSE W/O RSE WHT WIRE WHT/BLU WIRE WINDOW ANTENNA AMPLIFIER WINDOW ANTENNA AMPLIFIER 1 YEL/RED WIRE

Go to component -> Radio circuit, premium ihu (3 of 3) -> NCA WIRE

Wiring diagram nca (29 of 38)

Wiring diagram nca for Volvo S60 II facelift (2013-2018) (29 of 38)
Get lifetime access to Volvo S60 II facelift (2013-2018)

BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE BRN/BLU WIRE CEM CENTRAL ELECTRONIC MODULE (CEM) CLIMATE CONTROL MODULE (CCM) COMPUTER DATA LINES SYSTEM ENGINE COMPARTMENT DISTRIBUTION BOX GRN WIRE GRY WIRE GRY/ORG WIRE HEAD RESTRAINT RELAY HOT AT ALL TIMES LEFT HEAD RESTRAINT FOLDING MOTOR LEFT REAR HEAD RESTRAINT SOLENOID NCA WIRE ORG/ WIRE RED WIRE RIGHT END OF DASH) RIGHT HEAD RESTRAINT FOLDING MOTOR RIGHT REAR HEAD RESTRAINT SOLENOID VIO WIRE VIO/ORG WIRE

Go to component -> Rear head restraint circuit -> NCA WIRE

Wiring diagram nca (30 of 38)

Wiring diagram nca for Volvo S60 II facelift (2013-2018) (30 of 38)
Get lifetime access to Volvo S60 II facelift (2013-2018)

74/1 74/2 74/3 74/4 74/430 74/5 74/6 74/7 AUDIO MODULE (AUD) AUXILIARY INPUT (AUX) BLK WIRE BLK/GRN WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FUSE GRN WIRE GRN/ORG WIRE GROUND DISTRIBUTION SYSTEM GRY/ORG WIRE HOT W/ COMFORT FUNCTIONS RELAY ENERGIZED INFOTAINMENT CONTROL MODULE (ICM) INFOTAINMENT HEAD UNIT (IHU) INTEGRATED AUDIO MODULE (IAM) LEFT DISPLAY/DVD HEADREST MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE PASSENGER COMPARTMENT DISTRIBUTION BOX POWER DISTRIBUTION SYSTEM RED WIRE RED/VIO WIRE RIGHT DISPLAY/DVD HEADREST RIGHT END OF DASH) RSE CONTROL MODULE TV RECEIVER (TVM) VIO WIRE VIO/ORG WIRE WHT WIRE WHT/ORG WIRE WHT/RED WIRE YEL WIRE

Go to component -> Rear seat entertainment circuit -> NCA WIRE
