Volvo S60 II facelift (2013-2018) left rear seat backrest heating element Wiring diagram
This page shows the only wiring diagram for the component.left rear seat backrest heating element, which is found in the car Volvo S60 II facelift (2013-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear seat backrest heating element (1 of 1)
74/403
BLK WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLU WIRE
BLU/RED WIRE
BRN/VIO WIRE
CENTRAL ELECTRONIC MODULE (CEM)
COMPUTER DATA LINES SYSTEM
ENGINE COMPARTMENT DISTRIBUTION BOX
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/VIO WIRE
HOT W/ 15 FEED REAR RELAY ENERGIZED
HOT W/ 15 FEED RELAY ENERGIZED
LEFT REAR SEAT BACKREST HEATING ELEMENT
LEFT REAR SEAT CUSHION HEATING ELEMENT
LEFT REAR SEAT HEATER CONTROL MODULE
LEFT REAR SEAT TEMPERATURE SENSOR
ORG/ WIRE
PASSENGER COMPARTMENT DISTRIBUTION BOX
REAR HEATED SEAT SWITCH
RED WIRE
RIGHT END OF DASH)
RIGHT REAR SEAT BACKREST HEATING ELEMENT
RIGHT REAR SEAT CUSHION HEATING ELEMENT
RIGHT REAR SEAT HEATER CONTROL MODULE
RIGHT REAR SEAT TEMPERATURE SENSOR
VIO WIRE
VIO/GRN WIRE
WHT WIRE
WHT/GRN WIRE
WHT/ORG WIRE
Go to component -> Rear heated seats circuit -> LEFT REAR SEAT BACKREST HEATING ELEMENT
