Volvo S60 II facelift (2013-2018) electrohydraulic power steering module, electrical power steering control module Wiring diagram
This page shows the only wiring diagram for the component.electrohydraulic power steering module, electrical power steering control module, which is found in the car Volvo S60 II facelift (2013-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electrohydraulic power steering module, electrical power steering control module (1 of 1)
3.0L TURBO
AUXILIARY BRAKE LIGHTS
BATTERY MONITORING SENSOR
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRAKE CONTROL MODULE
CAPACITOR
COMBUSTION PREHEATER MODULE (CPM), RIGHT FRONT LAMP HOUSING
COOLING FAN CONTROL MODULE
ELECTROHYDRAULIC POWER STEERING MODULE, ELECTRICAL POWER STEERING CONTROL MODULE
FUEL PUMP
FUEL PUMP CONTROL MODULE
G-INFOT (FRONT PASSENGER'S DOOR SILL)
HEATED WINDSCREEN
KEYLESS VEHICLE MODULE (KVM)
LEFT "C" PILLAR)
PTC-ELEMENT, SECONDARY BATTERY
REAR WINDOW WIPER MOTOR
REAR WINDOW WIPER RELAY
REVERSING LIGHT CONTACT,
SPARK PLUG, IGNITION COILS
Go to component -> Ground distribution circuit (1 of 2) -> ELECTROHYDRAULIC POWER STEERING MODULE, ELECTRICAL POWER STEERING CONTROL MODULE
