Volvo S60 II facelift (2013-2018) ejector side fuel level sensor Wiring diagram
This page shows the only wiring diagram for the component.ejector side fuel level sensor, which is found in the car Volvo S60 II facelift (2013-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ejector side fuel level sensor (1 of 1)
2.0L TURBO 3.0L TURBO, 2.5L TURBO
74/301
74/511
BLK WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRAKE FLUID LEVEL SENSOR
CENTRAL ELECTRONIC MODULE
CENTRAL ELECTRONIC MODULE (CEM)
COMPUTER DATA LINES SYSTEM
COOLANT LEVEL SENSOR
DRIVER INFORMATION MODULE (DIM)
EJECTOR SIDE FUEL LEVEL SENSOR
ENGINE CONTROL MODULE (ECM)
FUEL PUMP
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
PARK BRAKE MODULE
PARKING BRAKE SWITCH
PUMP SIDE FUEL LEVEL SENSOR
RED/WHT WIRE
RIGHT END OF DASH)
TRANSMISSION CONTROL MODULE (TCM)
VIO/BRN WIRE
VIO/ORG WIRE
YEL/VIO WIRE
Go to component -> Instrument cluster circuit -> EJECTOR SIDE FUEL LEVEL SENSOR
