Fuel door release circuit for Volvo S60 II (2010-2013)
Fuel door release circuit
74/411
BLK WIRE
BLK/BLU WIRE
CEM
CENTRAL ELECTRONIC MODULE (RIGHT END OF DASH)
ENGINE COMPARTMENT DISTRIBUTION
FUEL FILLER COVER LOCK MOTOR (RIGHT SIDE OF TRUNK, NEAR FUEL FILLER)
FUSE
FUSE FUSE BOX (LEFT SIDE OF ENGINE COMPT)
GRN/VIO WIRE
HOT AT ALL TIMES
LIGHT SWITCH MODULE
RED/BLK WIRE
RED/BLU WIRE
YEL/BLU WIRE
