Car Wiring Diagrams for Starting circuit for Volvo S60 II (2010-2013)

15- FEED RELAY 74/302 ALTERNATOR BATTERY BATTERY FUSES BLK WIRE BLU WIRE BRN WIRE CHARGING CIRCUIT ENGINE COMPARTMENT DISTRIBUTION BOX FUSE GRN WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE NCA WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/VIO WIRE STARTER MOTOR STARTER MOTOR RELAY VIO WIRE VIO/BRN WIRE WHT WIRE YEL WIRE

22 10 18 74/301 32 74/301 ANTENNA RING/ IGNITION SWITCH ILLUMINATION BLK WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE CENTRAL ELECTRONIC MODULE CENTRAL ELECTRONIC MODULE (RIGHT END ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT) FUSE FUSE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE IGNITION SWITCH OF DASH) RED/BLK WIRE RED/BLU WIRE RED/VIO WIRE STEERING COLUMN LOCK MODULE (ON STEERING COLUMN) STEERING COLUMN LOCK RELAY VIO/BRN WIRE VIO/GRY WIRE VIO/ORG WIRE WHT WIRE YEL WIRE YEL/BLU WIRE
