Power top/sunroof circuit for Volvo S60 II (2010-2013)
Power top/sunroof circuit
1 2 3 4 5 6 7 8 9 10 VBAT GLOBAL CLOSE
74/414
74/504
BLK WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/GRY WIRE
CEM
COMFORT FUNCTIONS RELAY
DOME LIGHT SWITCH UNIT
FUSE
HOT AT ALL TIMES
HOT AT ALL TIMES CENTRAL ELECTRONIC MODULE (CEM) (RIGHT END OF DASH)
ORG/ WIRE
PASSENGER COMPARTMENT DISTRIBUTION BOX (RIGHT SIDE FUSE OF DASH)
POWER SUNROOF SWITCH
RED WIRE
RED/BRN WIRE
SUNROOF CONTROL MODULE
TILT VSPEED COMF FEED FWD BWD GND
VIO/BRN WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
YEL/ORG WIRE
