Parking assistant circuit for Volvo S60 II (2010-2013)
Parking assistant circuit
13 15 16 17 74/519
5 10 11 12 74/309
74/540
BLK/GRN WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
COMPUTER DATA LINES SYSTEM
FRONT PARKING ASSISTANCE SENSOR (LF/I)
FRONT PARKING ASSISTANCE SENSOR (LF/O)
FRONT PARKING ASSISTANCE SENSOR (RF/I)
FRONT PARKING ASSISTANCE SENSOR (RF/O)
FUSE COMPARTMENT DISTRIBUTION BOX (RIGHT SIDE OF DASH)
GRN/WHT WIRE
GRY/ORG WIRE
HOT W/ 15 FEED REAR RELAY ENERGIZED
PARKING ASSISTANCE MODULE (PAM) (RIGHT REAR OF LUGGAGE COMPT)
PASSENGER
REAR PARKING ASSISTANCE SENSOR (LR/I)
REAR PARKING ASSISTANCE SENSOR (RR/I)
REAR PARKING REAR PARKING ASSISTANCE ASSISTANCE SENSOR (RR/O) SENSOR (LR/O)
VIO/GRY WIRE
VIO/ORG WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
