Blind spot information system circuit for Volvo S60 II (2010-2013)
Blind spot information system circuit
74/507
74/508
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
CAMERA
CEM
CENTRAL ELECTRONIC MODULE (RIGHT END OF DASH)
COMPUTER DATA LINES SYSTEM
DOOR MIRROR)
DRIVER DOOR MODULE (IN DRIVER FRONT DOOR)
DRIVER'S DOOR POWER WINDOW SWITCHES
ENGINE COMPARTMENT DISTRIBUTION BOX (LEFT SIDE
FUSE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
LEFT POWER DOOR MIRROR (IN LEFT
MODULE
OF ENGINE COMPT)
ORG/ WIRE
PASSENGER COMPARTMENT FUSE DISTRIBUTION BOX (RIGHT SIDE OF DASH)
PASSENGER DOOR MODULE (IN PASSENEGR FRONT DOOR)
RED WIRE
RED/GRY WIRE
RELAY ENERGIZED
RIGHT POWER DOOR MIRROR (IN RIGHT DOOR MIRROR)
VIO WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT WIRE
YEL WIRE
