Driver information system circuit for Volvo S60 II (2010-2013)
Driver information system circuit
10 18 74/301
20 74/511
BLK WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BRAKE FLUID LEVEL SENSOR (ON BRAKE MASTER CYLINDER RESERVOIR)
CENTRAL ELECTRONIC MODULE
CENTRAL ELECTRONIC MODULE (CEM) (RIGHT END OF DASH)
COMPUTER DATA LINES SYSTEM
COOLANT LEVEL SENSOR (IN COOLANT TANK)
DRIVER INFORMATION MODULE
EJECTOR SIDE FUEL LEVEL SENSOR
ENGINE CONTROL MODULE (ECM)
FUEL PUMP (TOP OF FUEL TANK)
FUSE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
PARK BRAKE MODULE (LEFT SIDE OF LUGGAGE COMPT)
PUMP SIDE FUEL LEVEL SENSOR
RED/WHT WIRE
TRANSMISSION CONTROL MODULE (TCM) (ON TRANSMISSION)
VIO/BRN WIRE
VIO/ORG WIRE
YEL/VIO WIRE
