Volvo S60 II (2010-2013) passenger seat backrest heating element Wiring diagram
This page shows the only wiring diagram for the component.passenger seat backrest heating element, which is found in the car Volvo S60 II (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger seat backrest heating element (1 of 1)
15 74/409
2 74/30
2 74/31
2 74/401
3 74/417
74/409
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU WIRE
BRN WIRE
BRN/VIO WIRE
CLIMATE CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DRIVER SEAT TEMPERATURE SENSOR (IN DRIVER SEAT BOTTOM)
DRIVER'S SEAT BACKREST HEATING ELEMENT
DRIVER'S SEAT CUSHION HEATING ELEMENT
DRIVER'S SIDE SEAT HEATING MODULE (SHM) (UNDER DRIVER SEAT)
FUSE
GRN WIRE
GRY WIRE
HOT W/ 15 FEED REAR RELAY ENERGIZED
OF DASH)
ORG/ WIRE
PASSENGER COMPARTMENT DISTRIBUTION BOX (RIGHT SIDE
PASSENGER SEAT BACKREST HEATING ELEMENT
PASSENGER SEAT CUSHION HEATING ELEMENT
PASSENGER SEAT TEMPERATURE SENSOR (IN PASSENGER SEAT BOTTOM)
PASSENGER'S SIDE SEAT HEATING MODULE (UNDER PASSENGER SEAT)
RED WIRE
VIO WIRE
VIO/GRN WIRE
WHT WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Front heated seats circuit -> PASSENGER SEAT BACKREST HEATING ELEMENT
