Volvo S60 II (2010-2013) integrated audio module Wiring diagrams
This page contains all the electrical diagrams for the component. integrated audio module, in which he is found in the car Volvo S60 II (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
integrated audio module wiring diagram (1 of 5)
74/531
74/532
AUDIO MODULE (UNDER FRONT PASSENGER'S SEAT)
BLK/GRN WIRE
COMPUTER DATA LINES SYSTEM
DIGITAL AUDIO BROADCAST MODULE (DABM) (BEHIND CENTER REAR SEAT)
FUSE
G-84 (FRONT PASSENGER'S DOOR SILL)
GRN/ORG WIRE
GRY/ORG WIRE
GSM/GPS/RDAR ANTENNA (CENTER REAR OF ROOF)
HOT AT ALL TIMES
INFOTAINMENT CONTROL MODULE
INTEGRATED AUDIO MODULE
MOST DATA BUS CIRCUIT
NCA WIRE
ORG/ WIRE
PASSENGER COMPARTMENT DISTRIBUTION BOX (RIGHT SIDE OF DASH)
RED WIRE
STEERING WHEEL MODULE (SWM) (TOP OF STEERING COLUMN)
VIO/ORG WIRE
W/ TVM
WHT WIRE
WINDOW ANTENNA AMPLIFIER (IN RIGHT "C" PILLAR)
Go to component -> Digital radio circuit -> INTEGRATED AUDIO MODULE
integrated audio module wiring diagram (2 of 5)
74/404
74/529
AUDIO MODULE (UNDER FRONT PASSENGER'S SEAT)
DIGITAL AUDIO BROADCAST MODULE (BEHIND CENTER REAR SEAT)
INFOTAINMENT CONTROL MODULE
INTEGRATED AUDIO MODULE
ORG/ WIRE
PHONE MODULE (UNDER FRONT PASSENGER'S SEAT)
REMOTE DIGITAL AUDIO RECEIVER (BEHIND CENTER REAR SEAT)
TV RECEIVER (LEFT SIDE OF LUGGAGE COMPT)
Go to component -> Most data bus circuit -> INTEGRATED AUDIO MODULE
integrated audio module wiring diagram (3 of 5)
1 2 3 4 5 6 7 8 9 10 11 12 RF+
1 74/407 26 13 74/409
23 74/507
4 74/509
4 74/510
4 74/534
74/1015
74/403
74/405
74/409
74/412
74/421
74/508
AM/FM OUT
AUDIO OUT L
AUDIO OUT R
AUXILIARY INPUT (AUX)
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL MODULE (RSE) (UNDER REAR OF CENTER CONSOLE)
DATA
DOOR SPEAKER
FEED
FUSE
FUSE FUSE
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/BLK WIRE
GRY/ORG WIRE
GRY/RED WIRE
HOT AT ALL TIMES
INFOTAINMENT CONTROL MODULE
INTEGRATED AUDIO MODULE
LEFT FRONT
LEFT FRONT TWEETER
LEFT REAR DOOR SPEAKER
LF+
LF+ RF-
LR (-) RR (-)
MICROPHONE
MOST DATA BUS CIRCUIT
NAVIGATION SYSTEM
NAVIGATION SYSTEM COMPUTER DATA LINES SYSTEM NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
PASSENGER COMPARTMENT DISTRIBUTION BOX (RIGHT SIDE OF DASH)
RED WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR DOOR SPEAKER
SHIELD
TV ANTENNA
TV ANTENNA (IF EQUIPPED)
TV RECEIVER (LEFT SIDE OF LUGGAGE COMPARTMENT)
USB-PORT (ACCESSORIES)
V-BUS
VIO/BLK WIRE
VIO/ORG WIRE
VIO/RED WIRE
W/ REAR SEAT ENTERTAINMENT
W/O REAR SEAT ENTERTAINMENT
WHT WIRE
WHT/BRN WIRE
WINDOW ANTENNA AMPLIFIER (IN RIGHT "C" PILLAR)
WINDOW WINDOW AMPLIFIER 1 (ON LEFT 'C' PILLAR)
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Radio circuit, base -> INTEGRATED AUDIO MODULE
integrated audio module wiring diagram (4 of 5)
26 13 74/409
4 74/534
74/1015
74/403
74/405
74/409
74/412
74/420
74/421
AM/FM OUT
AUDIO OUT L
AUXILIARY RSE CONTROL INPUT MODULE (AUX) (UNDER REAR OF CENTER CONSOLE)
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DATA
FEED
FUSE
FUSE FUSE
GND AUDIO OUT R
GRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
INFOTAINMENT CONTROL MODULE (ICM)
INTEGRATED AUDIO MODULE
MICROPHONE
MOST DATA BUS CIRCUIT
NAVIGATION SYSTEM
NAVIGATION SYSYTEM
NAVIGATION SYSYTEM COMPUTER DATA LINES SYSTEM
NCA WIRE
ORG/ WIRE
PASSENGER COMPARTMENT DISTRIBUTION BOX (RIGHT SIDE OF DASH)
RED WIRE
SHIELD
TV ANTENNA
TV ANTENNA (IF EQUIPPED)
TV RECEIVER (LEFT SIDE OF LUGGAGE COMPT)
USB-PORT (ACCERIES) WINDOW ANTENNA AMPLIFIER 1 (ON LEFT "C" PILLAR)
V-BUS
VIO WIRE
VIO/ORG WIRE
VIO/RED WIRE
W/ REAR SEAT ENTERTAINMENT
W/O REAR SEAT ENTERTAINMENT
WHT WIRE
WHT/BRN WIRE
WINDOW ANTENNA AMPLIFIER (IN RIGHT "C" PILLAR)
YEL/RED WIRE
Go to component -> Radio circuit, premium (2 of 2) -> INTEGRATED AUDIO MODULE
integrated audio module wiring diagram (5 of 5)
4 74/534
AUDIO MODULE (UNDER FRONT PASSENGER'S SEAT)
BLK/GRY WIRE
COMPUTER DATA LINES SYSTEM
FUSE
G-84 (FRONT PASSENGER'S DOOR SILL)
GRN/ORG WIRE
GRY/ORG WIRE
GSM/GPS/RDAR ANTENNA (CENTER REAR OF ROOF)
HOT AT ALL TIMES
INFOTAINMENT CONTROL MODULE
INTEGRATED AUDIO MODULE
MOST DATA BUS CIRCUIT
NCA WIRE
ORG/ WIRE
PASSENGER COMPARTMENT DISTRIBUTION BOX (RIGHT SIDE OF DASH)
RED WIRE
REMOTE DIGITAL AUDIO RECEIVER (BEHIND CENTER REAR SEAT)
STEERING WHEEL MODULE (SWM) (TOP OF STEERING COLUMN)
VIO/ORG WIRE
W/ TELIVISION MODULE
WHT WIRE
Go to component -> Satellite radio circuit -> INTEGRATED AUDIO MODULE
