Supplemental restraints circuit for Volvo S60 I facelift (2004-2009)

BLK WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE BRN WIRE CONTACT REEL (CENTER OF STEERING COLUMN) DRIVER SIDE AIRBAG IGNITER (IN STEERING WHEEL) DRIVER SIDE AIRBAG IGNITER STAGE 2 (IN STEERING WHEEL ASSEMBLY) FRONT LEFT SEAT BELT TENSIONER IGNITER (ON LEFT "B" PILLAR) FRONT LEFT SIDE AIRBAG IGNITER (ON LEFT "B" PILLAR) GRN WIRE GRN/ORG WIRE HOT AT ALL TIMES IGNITION SWITCH NCA WIRE OFF ORG/ WIRE ORG/BLK WIRE PASSENGER SIDE AIRBAG IGNITER (RIGHT SIDE OF DASH) PASSENGER SIDE AIRBAG STAGE 2 IGNITER (RIGHT SIDE OF DASH) RED WIRE SOLID STATE SUPPLEMENTAL RESTRAINTS SYSTEM (BELOW REAR OF CENTER CONSOLE) VIO WIRE YEL/WHT WIRE

3 6 11 14 DATA LINK CONNECTOR (PARTIAL) (BELOW LEFT SIDE OF DASH) BLK WIRE BLU/RED WIRE BRN WIRE CENTRAL ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH) DRIVER INFORMATION MODULE (DIM) (IN INSTRUMENT CLUSTER) FUSE 10 GRN WIRE GRN/ORG WIRE GRN/WHT WIRE HOT AT RUN AND START LEFT REAR SIDE IMPACT SENSOR (AT LEFT REAR QUARTER PANEL) LEFT SEAT BELT BUCKLE SWITCH NCA WIRE ORG/ WIRE ORG/BLK WIRE SOLID STATE VIO WIRE WHT WIRE YEL/WHT WIRE

BLK WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE BRN WIRE CENTER REAR SEAT BELT TENSIONER IGNITER (IN TOP CENTER OF REAR SEAT) COMPUTER DATA LINES SYSTEM GRN WIRE GRN/ORG WIRE GRN/WHT WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE REAR RIGHT BELT TENSIONER IGNITER (ON RIGHT "C" PILLAR) RIGHT FRONT SIDE IMPACT SENSOR (ON RIGHT "B" PILLAR) RIGHT INFLATABLE CURTAIN IGNITER (ON RIGHT "C" PILLAR) RIGHT REAR SIDE IMPACT SENSOR (AT RIGHT REAR QUARTER PANEL) RIGHT SEAT BELT BUCKLE SWITCH SOLID STATE SUPPLEMENTAL RESTRAINTS SYSTEM (BELOW REAR OF CENTER CONSOLE) VIO WIRE WHT WIRE
