Back-up lamps circuit for Volvo S60 I facelift (2004-2009)
Back-up lamps circuit
BLK WIRE
BLU WIRE
CENTRAL ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
FUSE 1
GRN WIRE
GRN/YEL WIRE
HOT AT ALL TIMES MAIN FUSES (NEXT TO BATTERY) FUSE
LEFT REAR LAMP HOUSING
LEFT REVERSING LIGHT
REAR ELECTRONIC MODULE (REM) (AT LEFT REAR CORNER OF TRUNK)
RED WIRE
REVERSING LIGHT CONTACT (M/T)
RIGHT REAR LAMP HOUSING
RIGHT REVERSING LIGHT
WHT WIRE
YEL/GRY WIRE
