Volvo S60 I facelift (2004-2009) window antenna amplifier solid state Wiring diagrams
This page contains all the electrical diagrams for the component. window antenna amplifier solid state, in which he is found in the car Volvo S60 I facelift (2004-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram window antenna amplifier solid state (1 of 2)
+ANT +CS -CS GND
AUDIO PHONE SWITCH
BLU/WHT WIRE
BRAKE CONTROL MODULE (AT LEFT REAR OF ENGINE COMPT)
BRN WIRE
BUMPER ANTENNA
BUMPER ANTENNA AMPLIFIER SOLID STATE
CENTER DASHBOARD SPEAKER
CENTRAL ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH)
CLIMATE CONTROL MODULE
COMPUTER DATA LINES SYSTEM
CONTACT REEL
CRUISE CONTROL SWITCH (SWS)
DIN (OR COAXIAL CABLE)
DIN (OR COAXIAL CABLE) DIN (OR COAXIAL CABLE)
FUSE
FUSE FUSE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
LEFT FRONT DOOR SPEAKER
LEFT FRONT TWEETER
LEFT REAR DOOR SPEAKER
LEFT REAR SHELF SPEAKER
NCA WIRE
PASSENGER COMPARTMENT)
RED WIRE
RELAY BOX (BEHIND LEFT SIDE OF DASH)
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR DOOR SPEAKER
RIGHT REAR SHELF SPEAKER
SOLID STATE
STEERING WHEEL MODULE (SWM)
VIO WIRE
WHT WIRE
WINDOW ANTENNA
WINDOW ANTENNA AMPLIFIER SOLID STATE
Go to component -> Radio circuit, with amplifier -> WINDOW ANTENNA AMPLIFIER SOLID STATE
Wiring diagram window antenna amplifier solid state (2 of 2)
+RF -RF +LR
ANT
AUDIO PHONE SWITCH
BLU/WHT WIRE
BRAKE CONTROL MODULE (AT LEFT REAR OF ENGINE COMPT)
BRN WIRE
BUMPER ANTENNA
BUMPER ANTENNA AMPLIFIER
CLIMATE CONTROL MODULE
COMPUTER DATA LINES SYSTEM
CONTACT REEL
CRUISE CONTROL SWITCH (SWS)
DIN (OR COAXIAL CABLE)
DIN (OR COAXIAL CABLE) DIN (OR COAXIAL CABLE)
FUSE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES PASSENGER COMPARTMENT RELAY BOX (BEHIND LEFT SIDE OF DASH)
HOT IN ON OR ACC CENTRAL ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH) FUSE
LEFT FRONT DOOR SPEAKER
LEFT FRONT TWEETER
LEFT REAR DOOR SPEAKER
LEFT REAR SHELF SPEAKER
LF+
LR (-)
NCA WIRE
RED WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR DOOR SPEAKER
RIGHT REAR SHELF SPEAKER
RR (-)
SOLID STATE
STEERING WHEEL MODULE (SWM)
VIO WIRE
WHT WIRE
WINDOW ANTENNA
WINDOW ANTENNA AMPLIFIER SOLID STATE
Go to component -> Radio circuit, without amplifier -> WINDOW ANTENNA AMPLIFIER SOLID STATE
