Volvo S60 I facelift (2004-2009) forward/ backward switch Wiring diagrams
This page contains all the electrical diagrams for the component. forward/ backward switch, in which he is found in the car Volvo S60 I facelift (2004-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram forward/ backward switch (1 of 3)
BACK
BATTERY FUSE BOX
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/YEL WIRE
CENTRAL ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH)
DOWN
DRIVER SEAT BACKREST ANGLE MOTOR (IN DRIVER'S SEAT BACK)
DRIVER SEAT FORWARD/BACKWARD MOTOR (IN DRIVER SEAT)
DRIVER SEAT FRONT EDGE UP/DOWN MOTOR (IN DRIVER'S SEAT BOTTOM)
DRIVER SEAT REAR EDGE UP/DOWN MOTOR (IN DRIVER'S SEAT BOTTOM)
DRIVER'S SIDE POWER SEAT SWITCH
FORW
FORWARD/ BACKWARD SWITCH
FRONT EDGE UP/DOWN SWITCH
FUSE
FUSE 10
FUSE RELAY & FUSE BOX (BEHIND LEFT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
HOT AT ALL TIMES
LUMBAR SWITCH
PASSENGER COMPARTMENT)
POSITION
POSITION 1
POSITION 2
POSITION 3
POWER SEAT MODULE (PSM) (UNDER SEAT)
REAR EDGE UP/DOWN SWITCH
REARW
RED WIRE
VIO WIRE
VIO/BLK WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Driver power seat circuit -> FORWARD/ BACKWARD SWITCH
Wiring diagram forward/ backward switch (2 of 3)
BACK
BACKREST ANGLE SWITCH
BATTERY FUSE BOX
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/YEL WIRE
CENTRAL ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH)
DOWN
DRIVER SEAT BACKREST ANGLE MOTOR (IN DRIVER'S SEAT BACK)
DRIVER SEAT FORWARD/BACKWARD MOTOR (IN DRIVER SEAT)
DRIVER SEAT FRONT EDGE UP/DOWN MOTOR (IN DRIVER'S SEAT BOTTOM)
DRIVER SEAT REAR EDGE UP/DOWN MOTOR (IN DRIVER'S SEAT BOTTOM)
DRIVER'S SIDE POWER SEAT SWITCH
FORW
FORWARD/ BACKWARD SWITCH
FUSE
FUSE 10
FUSE RELAY & FUSE BOX (BEHIND LEFT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
HOT AT ALL TIMES
PASSENGER COMPARTMENT)
POSITION
POSITION 1
POSITION 2
POSITION 3
POWER SEAT MODULE (PSM) (UNDER SEAT)
REARW
RED WIRE
UP FRONT EDGE UP/DOWN SWITCH
UP REAR EDGE UP/DOWN SWITCH
VIO WIRE
VIO/BLK WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Driver"s memory seat circuit -> FORWARD/ BACKWARD SWITCH
Wiring diagram forward/ backward switch (3 of 3)
BACKREST SWITCH
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
CENTRAL ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH) FUSE 28
DOWN
FORW
FORW BACK
FORWARD/ BACKWARD SWITCH
FRONT EDGE UP/DOWN SWITCH
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
HOT AT ALL TIMES BATTERY FUSE FUSE BOX
HOT AT ALL TIMES PASSENGER FUSE COMPARTMENT FUSE BOX (AT LEFT END OF DASH)
PASSENGER UP/DOWN REAR EDGE SEAT MOTOR
POWER PASSENGER SEAT MODULE
REAR EDGE UP/DOWN SWITCH
RED WIRE
STOP LOGIC
UP BACK
UP DOWN
VIO WIRE
VIO/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Passenger"s power seat circuit -> FORWARD/ BACKWARD SWITCH
