Anti-lock brake circuits, with dynamic stability control for Volvo S60 I (2000-2004)

2 3 8 9 COMPUTER DATA LINES SYSTEM ABS CONTROL MODULE (ON LEFT REAR OF ENGINE COMPT) ABS PUMP MOTOR BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/WHT WIRE BRAKE LIGHT CONTACT BRAKE PEDAL SENSOR BRAKE PRESSURE SENSOR 1 (ON BRAKE MASTER CYLINDER) BRN WIRE BRN/BLK WIRE BRN/ORG WIRE BRN/PNK WIRE BRN/WHT WIRE CENTRAL ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH) CLIMATE CONTROL MODULE COMPUTER DATA LINES SYSTEM CONTACT REEL DSTC ACTIVATION UNIT (AT STEERING COLUMN) DSTC SENSOR MODULE ENGINE COMPARTMENT RELAY/FUSE BOX (LEFT SIDE OF ENGINE COMPT) FUSE ENGINE CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT) FUSE GRN WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/ORG WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT CLUSTER LEFT FRONT ABS SENSOR (ON WHEEL HUB) NCA WIRE ORG/WHT WIRE PASSENGER COMPARTMENT FUSE BOX (AT LEFT END OF DASH) FUSE PNK PNK WIRE PNK WIRE PNK/WHT WIRE RED WIRE RED/WHT WIRE RIGHT FRONT ABS SENSOR (ON WHEEL HUB) RIGHT REAR ABS SENSOR (ON WHEEL HUB) SPIN CONTROL SWITCH STEERING ANGLE SENSOR MODULE STEERING WHEEL MODULE (SWM) VACUUM PUMP VACUUM PUMP SWITCH WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/GRY WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE
