Volvo S60 I (2000-2004) overload relay 15-feed Wiring diagram
This page shows the only wiring diagram for the component.overload relay 15-feed, which is found in the car Volvo S60 I (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram overload relay 15-feed (1 of 1)
ANTENNA RING/ IGNITION SWITCH LIGHTING
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRAKE CONTROL MODULE
CENTRAL ELECTRONIC MODULE
DRL RELAY
ENGINE CONTROL MODULE
FROM
FRONT 12 VOLT OUTLET
FUSE
FUSE FUSE
FUSE FUSE FUSE
FUSE FUSE FUSE FUSE
GRN/RED WIRE
IGNITION SWITCH
KEY IN
KEY-IN IGNITION SWITCH
LEFT SEAT HEATER RIGHT SEAT HEATER
LEFT/ RIGHT HEADLIGHT WIPER MOTOR, LEFT/RIGHT BEAM ADJUSTMENT ACTUATOR
OFF
OVERLOAD RELAY 15-FEED
OVERLOAD RELAY X FEED
PASSENGER COMPARTMENT FUSE BOX
POWER DRIVER SEAT MODULE
POWER PASSENGER SEAT MODULE
RADIO, RTI DISPLAY RADIO FRONT FOG LIGHT RELAY
REAR CIGA- RETTE LIGHTER 12 VOLT OUTLET
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RTI DISPLAY
STARTER MOTOR RELAY (DIAGRAM 2 OF 3)
STEERING ANGLE SENSOR CONTROL MODULE
SUPPLEMENTAL RESTRAINT SYSTEM CONTROLS UNIT
VIO WIRE
YEL WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Power distribution circuit (3 of 3) -> OVERLOAD RELAY 15-FEED
