Volvo S60 I (2000-2004) left seat belt lock switch wiring diagram
This page shows the only wiring diagram for the component.left seat belt lock switch, which is found in the car Volvo S60 I (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left seat belt lock switch wiring diagram (1 of 1)
BLK WIRE
BRAKE CONTROL MODULE (ON LEFT REAR OF ENGINE COMPT)
BRN WIRE
BRN/GRY WIRE
BRN/PNK WIRE
CENTRAL ELECTRONIC MODULE (ON PASSENGER COMPT RELAY BOX)
COMBINED INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
FUSE
GRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES IGNITION SWITCH
HOT W/ OVERLOAD RELAY (15-FEED) ENERGIZED
KEY-IN IGNITION SWITCH
LEFT FRONT ABS SENSOR (ON WHEEL HUB)
LEFT SEAT BELT LOCK SWITCH
OFF
ORG/BLK WIRE
PASSENGER COMPARTMENT FUSE BOX (AT LEFT END OF DASH)
RED WIRE
RIGHT FRONT ABS SENSOR (ON WHEEL HUB)
RIGHT SEAT BELT LOCK SWITCH
STEERING WHEEL MODULE
UPPER ELECTRONIC MODULE (ON REARVIEW MIRROR)
VIO WIRE
WHT WIRE
YEL WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Warning system circuits -> LEFT SEAT BELT LOCK SWITCH
