Volvo S60 I (2000-2004) folding door mirrors switch Wiring diagram
This page shows the only wiring diagram for the component.folding door mirrors switch, which is found in the car Volvo S60 I (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram folding door mirrors switch (1 of 1)
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CLIMATE CONTROL MODULE
COMPUTER DATA LINES SYSTEM
FOLD-BACK
FOLDING DOOR MIRRORS SWITCH
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR CONTROL MODULE
LEFT POWER DOOR MIRROR
PASSENGER COMPARTMENT FUSE BOX
PNK WIRE
RED WIRE
RED/WHT WIRE
RIGHT FRONT DOOR CONTROL MODULE
RIGHT POWER DOOR MIRROR
WHT WIRE
X-DIRECTION
Y-DIRECTION
Go to component -> Power mirror circuit -> FOLDING DOOR MIRRORS SWITCH
