Parking assistant circuit for Volvo S60 Cross Country I (2015-2018)
Parking assistant circuit
74/309
74/519
74/540
BLK/GRN WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
COMPUTER DATA LINES SYSTEM
FRONT PARKING ASSISTANCE SENSOR (LF/I)
FRONT PARKING ASSISTANCE SENSOR (LF/O)
FRONT PARKING ASSISTANCE SENSOR (RF/I)
FRONT PARKING ASSISTANCE SENSOR (RF/O)
GRN/BLK WIRE
GRN/WHT WIRE
GRY/ORG WIRE
HOT W/ 15 FEED REAR RELAY ENERGIZED
LEFT SIDE PARKING SENSOR
PARKING ASSISTANCE MODULE (PAM)
PASSENGER COMPARTMENT DISTRIBUTION BOX
REAR PARKING ASSISTANCE SENSOR (LR/I)
REAR PARKING ASSISTANCE SENSOR (LR/O)
REAR PARKING ASSISTANCE SENSOR (RR/I)
REAR PARKING ASSISTANCE SENSOR (RR/O)
RIGHT END OF DASH)
RIGHT SIDE PARKING SENSOR
VIO/GRY WIRE
WHT/BRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
