Volvo S60 Cross Country I (2015-2018) remote keyless entry, remote receiver module Wiring diagram
This page shows the only wiring diagram for the component.remote keyless entry, remote receiver module, which is found in the car Volvo S60 Cross Country I (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram remote keyless entry, remote receiver module (1 of 1)
BLK WIRE
BLU WIRE
BRAKE LIGHT CONTACT
BRN WIRE
CENTRAL ELECTRONIC MODULE
CLIMATE CONTROL MODULE
DATA LINK CONNECTOR
DRIVER INFORMATION MODULE
FORWARD SENSING MODULE
FORWARD-AIMED RADAR
FROM ENGINE COMPARTMENT COLD ZONE DISTRIBUTION BOX (DIAGRAM 4 OF 4)
FROM ENGINE COMPARTMENT DISTRIBUTION BOX (DIAGRAM 1 OF 4)
FUEL FILLER COVER LOCK MOTOR
FUEL PUMP CONTROL MODULE
GRN WIRE
GRY WIRE
HEAD RESTRAINT RELAY
HEATED STEERING WHEEL MODULE (HSWM)
IGNITION SWITCH
IMMOBILIZER ANTENNA UNIT
INTERIOR LIGHT RELAY
ORG/ WIRE
PASSENGER SIDE HEATED WINDSHIELD RELAY
REAR WINDOW WIPER MOTOR, REAR WINDOW WIPER RELAY
RED WIRE
RED/BLK WIRE
RED/VIO WIRE
REMOTE KEYLESS ENTRY, REMOTE RECEIVER MODULE
RIGHT END OF DASH)
SIREN CONTROL MODULE
STEERING COLUMN LOCK MODULE
STEERING WHEEL MODULE
SUNROOF CONTROL MODULE
TAILGATE CENTRAL LOCKING MOTOR
VIO WIRE
VIO/GRY WIRE
W/O START/STOP FUNCTION W/ START/STOP FUNCTION
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> REMOTE KEYLESS ENTRY, REMOTE RECEIVER MODULE
