Volvo S60 Cross Country I (2015-2018) front edge up/down switch Wiring diagram
This page shows the only wiring diagram for the component.front edge up/down switch, which is found in the car Volvo S60 Cross Country I (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front edge up/down switch (1 of 1)
74/31
BACK
BACKREST SWITCH
BLK WIRE
BLK/GRN WIRE
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
DOWN
FORWARD/
FORWARD/ BACKWARD SWITCH
FRONT EDGE UP/DOWN SWITCH
GRN WIRE
HOT AT ALL TIMES
ORG/ WIRE
ORG/BLU WIRE
PASSENGER BACKREST ANGLE SEAT MOTOR
PASSENGER COMPARTMENT DISTRIBUTION BOX
PASSENGER FORWARD/ BACKWARD SEAT MOTOR
PASSENGER POWER SEAT SWITCH UNIT
PASSENGER UP/DOWN FRONT EDGE SEAT MOTOR
PASSENGER UP/DOWN REAR EDGE SEAT MOTOR
REAR EDGE UP/DOWN SWITCH
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT END OF DASH)
STOP LOGIC
WHT/BLK WIRE
YEL/WHT WIRE
Go to component -> Passenger"s power seat circuit -> FRONT EDGE UP/DOWN SWITCH
