Volvo S60 Cross Country I (2015-2018) battery monitoring sensor Wiring diagram
This page shows the only wiring diagram for the component.battery monitoring sensor, which is found in the car Volvo S60 Cross Country I (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram battery monitoring sensor (1 of 1)
3.0L TURBO
AUXILIARY BRAKE LIGHTS
BATTERY MONITORING SENSOR
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRAKE CONTROL MODULE
COMBUSTION PREHEATER MODULE (CPM),
COOLING FAN CONTROL MODULE
DRIVER DOOR MODULE, LEFT REAR DOOR MODULE, POWER SEAT MODULE,
DRIVER'S SIDE SEAT HEATING MODULE
ELECTRICAL POWER STEERING CONTROL MODULE
FUEL FILLER COVER LOCK MOTOR
FUEL PUMP
FUEL PUMP CONTROL MODULE
G-INFOT (FRONT PASSENGER'S DOOR SILL)
HEATED WINDSCREEN
KEYLESS VEHICLE MODULE, RIGHT REAR LAMP HOUSING,
LEFT "C" PILLAR)
PARK BRAKE MODULE (PBM), AUXILIARY BRAKE LIGHT
PTC-ELEMENT, SECONDARY BATTERY
REAR WINDOW WIPER MOTOR
REAR WINDOW WIPER RELAY
RIGHT FRONT LAMP HOUSING
SPARK PLUG, IGNITION COILS, CAPACITOR
TRUNK LID/TAILGATE CENTRAL LOCKING MOTOR
Go to component -> Ground distribution circuit (1 of 2) -> BATTERY MONITORING SENSOR
