Wiring diagram engine performance 2.5l turbo for Volvo S40 II (2004-2007)

BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE COOLANT TEMPERATURE SENSOR (FRONT OF ENGINE COMPT) ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT) EVAP VALVE (AT RIGHT REAR OF ENGINE) GRN/BLU WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE INTAKE MANIFOLD PRESSURE, TEMPERATURE SENSOR (RIGHT FRONT OF ENGINE COMPT) NCA WIRE OIL PRESSURE MONITOR REAR HEATED OXYGEN SENSOR (DOWNSTREAM OF CATALYTIC CONVERTER) TURBOCHARGER CONTROL VALVE (RIGHT SIDE OF ENGINE) WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE

BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE ENGINE COMPARTMENT DISTRIBUTION BOX (LEFT SIDE OF ENGINE COMPT) ENGINE MANAGEMENT SYSTEM MAIN RELAY ENGINE THROTTLE BODY (AT REAR OF ENGINE) FUSE FUSE FUSE 34 GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES NCA WIRE OIL TRAP PTC RESISTOR (ON LOWER FRONT OF HVAC) RED/ORG WIRE SPARK PLUGS, IGNITION COILS (TOP OF ENGINE) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE

BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT) GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE GRY/WHT WIRE IMPULSE SENSOR (ON TOP REAR OF ENGINE) RED WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE

ACCELERATOR PEDAL SENSOR (NEAR ACCELERATOR PEDAL) BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE CENTRAL ELECTRONIC MODULE (CEM) CLIMATE CONTROL RELAY COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM COOLING FANS SYSTEM STARTING/CHARGING SYSTEM ENGINE COMPARTMENT DISTRIBUTION BOX (LEFT SIDE OF ENGINE COMPT) ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT) FRONT HEATED OXYGEN SENSOR (UPSTREAM OF CATALYTIC CONVERTER) FUEL LEAKAGE CONTROL PUMP (UNDER REAR OF VEHICLE, NEAR FUEL PUMP RELAY FUEL TANK FUSE GRN/BLU WIRE GRN/GRY WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES NCA WIRE ORG/ WIRE ORG/WHT WIRE RED WIRE STARTING/CHARGING SYSTEM COOLING FANS SYSTEM VARIABLE VALVE TIMING OUTLET SOLENOID (ON TOP RIGHT OF ENGINE) WHT WIRE WHT/BLK WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/RED WIRE YEL/VIO WIRE
