Manual a/c circuit for Volvo S40 II (2004-2007)

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/YEL WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE CLIMATE CONTROL MODULE (CCM) CLIMATE CONTROL SYSTEM RELAY COMPUTER DATA LINES SYSTEM DEFROSTER DAMPER MOTOR (LEFT SIDE OF HVAC HOUSING) ELECTROMAGNETIC CLUTCH (CLIMATE CONTROL SYSTEM) (LEFT FRONT OF ENGINE) ENGINE COMPARTMENT DISTRIBUTION BOX (LEFT SIDE OF ENGINE COMPT) ENGINE MANAGEMENT MAIN RELAY EVAPORATOR TEMERATURE SENSOR (NEAR CENTER OF HVAC HOUSING) FAN CONTROL MODULE FLOOR/VENTILATION DAMPER MOTOR (LEFT SIDE OF HVAC HOUSING) FUSE 27 FUSE 3 FUSE 16 FUSE 34 FUSE 35 FUSE 28 FUSE 9 FUSE 10 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/RED WIRE HOT AT ALL TIMES INFOTAINMENT RELAY 2 LEFT SIDE TEMPERATURE DAMPER MOTOR (ON RIGHT SIDE OF HVAC HOUSING) NCA WIRE ORG/GRN WIRE RECIRCULATION DAMPER MOTOR (ON LOWER RIGHT SIDE OF HVAC HOUSING) RED WIRE RED/BLU WIRE RED/ORG WIRE RED/WHT WIRE VIO WIRE WHT WIRE WHT/GRN WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/RED WIRE BRN/YEL WIRE CENTRAL ELECTRONIC MODULE (CEM) (BEHIND RIGHT SIDE OF DASH) CLIMATE CONTROL SYSTEM PRESSURE MONITOR CLIMATE CONTROL SYSTEM PRESSURE SENSOR (AT RIGHT REAR OF ENGINE COMPT) COMFORT FUNCTIONS RELAY DRIVER'S DOOR MODULE DRIVER'S DOOR POWER REAR ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT) FUSE 66 FUSE 69 GRN/YEL WIRE INFOTAINMENT RELAY NCA WIRE ORG/GRN WIRE PASSENGER COMPARTMENT FAN MOTOR (BEHIND CENTER OF DASH) RED/ORG WIRE RED/WHT WIRE SOLAR TWILLIGHT SENSOR, INDICATOR ALARM (ON TOP CENTER OF DASH) VIEW MIRROR WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/RED WIRE
