Volvo S40 II (2004-2007) engine control module (left front of wiring diagram
This page shows the only wiring diagram for the component.engine control module (left front of, which is found in the car Volvo S40 II (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
engine control module (left front of wiring diagram (1 of 1)
2.4L
ADDITIVE DOSING MODULE (BEHIND LEFT REAR SEAT)
ALTERNATOR
AM/FM TUNER MODULE (RIGHT REAR OF VEHICLE)
AUTOMATIC TRANSMISSION PROGRAM SELECTOR
BLK WIRE
BLU/RED WIRE
BLU/YEL WIRE
DRIVER'S DOOR MODULE (IN DRIVER'S DOOR)
DRIVER'S POWER SEAT SWITCH UNIT
ENGINE COMPT)
ENGINE CONTROL MODULE (LEFT FRONT OF
GRY/BLK WIRE
GRY/RED WIRE
KEYLESS VEHICLE MODULE (UNDER DRIVER'S SEAT)
LEFT REAR DOOR MODULE (IN LEFT REAR DOOR)
NCA WIRE
ORG/ WIRE
PASSENGER POWER SEAT SWITCH UNIT
REVERSE INTERLOCK SOLENOID (AT BASE OF SHIFT LEVER ASSEMBLY)
STEERING WHEEL MODULE
TRAFFIC MESSAGE CHANNEL MODULE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Computer data lines circuit (3 of 3) -> ENGINE CONTROL MODULE (LEFT FRONT OF
