Car Wiring Diagrams for Heated seats circuit for Volvo C70 II (2005-2009)

BACKREST BLK WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE CENTRAL ELECTRONIC MODULE CENTRAL ELECTRONIC MODULE (BEHIND RIGHT SIDE OF DASH) CLIMATE CONTROL MODULE (CCM) COMFORT FUNCTIONS RELAY COMPUTER DATA LINES SYSTEM CUSHION) DRIVER'S SEAT DRIVER'S SIDE SEAT HEATER MODULE (UNDER DRIVER'S SEAT) ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPARTMENT) FUSE 3 FUSE 60 FUSE 61 GRN WIRE GRY WIRE GRY/BLK WIRE GRY/RED WIRE HEATING COIL ORG/ WIRE PASSENGER'S SEAT BACKREST HEATER PASSENGER'S SEAT CUSHION HEATING COIL PASSENGER'S SEAT TEMPERATURE SENSOR (IN PASSENGER FRONT PASSENGER'S SIDE SEAT HEATER MODULE (UNDER FRONT PASSENGER'S SEAT) RED WIRE SEAT CUSHION) SENSOR TEMPERATURE W/ TURBO W/O TURBO WHT WIRE WHT/GRN WIRE YEL WIRE
