Computer data lines circuit for Volvo C70 II (2005-2009)

BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE BODY SENSOR CLUSTER STABILITY SENSOR (UNDER FRONT PASSENGER'S SEAT) BRAKE CONTROL MODULE (LEFT REAR CORNER OF ENGINE COMPT) CENTRAL ELECTRONIC MODULE CENTRAL ELECTRONIC MODULE (CEM) (BEHIND RIGHT SIDE OF DASH) COMBUSTION PREHEATER MODULE (RIGHT FRONT OF ENGINE COMPT) DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) DIFFERENTIAL ELECTRONIC MODULE (AT REAR DIFFERENTIAL) ELECTRICAL POWER STEERING MODULE (IF EQUIPPED) ENGINE COMPARTMENT DISTRIBUTION BOX (LEFT SIDE OF ENGINE COMPT) FUSE GRY WIRE GRY/BLK WIRE GRY/ORG WIRE GRY/RED WIRE HOT AT ALL TIMES IGNITION SWITCH ORG/ WIRE RED WIRE RED/YEL WIRE REMOTE RECEIVER MODULE (TOP OF INSTRUMENT CLUSTER) STEERING COLUMN LOCK MODULE (TOP RIGHT SIDE OF STEERING COLUMN) WHT WIRE WHT/GRN WIRE WHT/RED WIRE WIPER MOTOR MODULE (ON RIGHT SIDE OF PLENUM) YEL WIRE

ACCESSORY ELECTRONIC MODULE (RIGHT REAR CORNER OF CARGO COMPT) BLK WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE CLIMATE CONTROL MODULE CONVERTIBLE ROOF MODULE (RIGHT SIDE OF LUGGAGE COMPT) DRIVER INFORMATION MODULE GRN WIRE GRY/BLK WIRE GRY/ORG WIRE GRY/RED WIRE GRY/VIO WIRE INFOTAINMENT CONTROL MODULE INTEGRATED AUDIO MODULE LEFT GAS DISCHARGE LAMP MASTER CONTROL MODULE (BEHIND LEFT HEADLIGHT) MULTIMEDIA MODULE (IF EQUIPPED) ORG/ WIRE PARKING ASSISTANCE MODULE (RIGHT REAR CORNER OF CARGO COMPT) PASSENGER DOOR MODULE (IN FRONT PASSENGER'S DOOR) PHONE MODULE (IF EQUIPPED) RAIN SENSOR MODULE (FRONT CENTER OF ROOF) RIGHT GAS DISCHARGE LAMP MASTER CONTROL MODULE (BEHIND RIGHT HEADLIGHT) RIGHT REAR DOOR MODULE (IN RIGHT REAR DOOR) SIREN CONTROL MODULE (AT RIGHT REAR OF ENGINE COMPT) TO AUDIO MODULE (DIAGRAM 4 OF 4) TRAILER MODULE (LEFT REAR OF TRUNK) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE

64/245 CONNECTOR (LEFT REAR OF LUGGAGE COMPT) ADDITIVE DOSING MODULE (BEHIND LEFT REAR SEAT) ALTERNATOR AUTOMATIC TRANSMISSION PROGRAM SELECTOR BLK WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE CLIMATE CONTROL SYSTEM DRIVER'S DOOR MODULE (IN DRIVER'S DOOR) DRIVER'S POWER SEAT MODULE DRIVER'S SIDE SEAT HEATING MODULE (UNDER DRIVER'S SEAT) ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) GEAR SELECTOR MODULE (AT BASE OF SHIFT LEVER ASSEMBLY) GRN WIRE GRY/BLK WIRE GRY/RED WIRE KEYLESS VEHICLE MODULE (UNDER DRIVER'S SEAT) LEFT REAR DOOR MODULE (IN LEFT REAR DOOR) OCCUPANT WEIGHT SENSOR (IN FRONT PASSENGER'S SEAT) PASSENGER'S POWER SEAT MODULE PASSENGER'S SIDE SEAT HEATING MODULE (UNDER PASSENGER'S SEAT) RED WIRE STEERING WHEEL MODULE TURBO ENGINE EXCEPT TURBO ENGINE VIO WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE

AUDIO MODULE AUDIO MODULE (LEFT SIDE OF TRUNK) FROM INTEGRATED AUDIO MODULE GLOBAL POSITIONING SYSTEM MODULE (LEFT SIDE OF TRUNK) ORG/ WIRE REMOTE DIGITAL AUDIO RECEIVER REMOTE DIGITAL AUDIO RECEIVER (RIGHT REAR OF TRUNK) SUB WOOFER GLOBAL POSITIONING SYSTEM MODULE (LEFT SIDE OF TRUNK) SUBWOOFER MODULE (LEFT SIDE OF TRUNK) TRAFFIC MESSAGE CHANNEL MODULE (BEHIND RIGHT SIDE OF DASH) W/ PREMIUM AUDIO SYSTEM W/ PREMIUM AUDIO SYSTEM, GPS, SUBWOOFER, REMOTE DIGITAL AUDIO RECEIVER W/ PREMIUM AUDIO SYSTEM, GPS, SUBWOOFER, TRAFFIC MESSAGE CHANNEL W/ PREMIUM AUDIO SYSTEM, GPS, TRAFFIC MESSAGE CHANNEL W/ PREMIUM AUDIO SYSTEM, SUBWOOFER W/ PREMIUM AUDIO SYSTEM, SUBWOOFER, REMOTE DIGITAL AUDIO RECEIVER
