Volvo C70 II (2005-2009) engine compartment distribution Wiring diagram
This page shows the only wiring diagram for the component.engine compartment distribution, which is found in the car Volvo C70 II (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine compartment distribution (1 of 1)
AUTO DIMMING REARVIEW MIRROR
BLK WIRE
BLU WIRE
CEM
CENTRAL ELECTRONIC MODULE (BEHIND RIGHT FUSE 73 SIDE OF DASH)
ENGINE COMPARTMENT DISTRIBUTION
FUSE 18 FUSE 26 BOX (LEFT SIDE OF ENGINE COMPT)
FUSE 4
FUSE 79
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
IGNITION SWITCH
ON LOCK OFF
ORG/ WIRE
RED WIRE
REVERSING LIGHTS RELAY
YEL WIRE
Go to component -> Auto dimming rear view mirror circuit -> ENGINE COMPARTMENT DISTRIBUTION
