Volvo C70 II (2005-2009) clutch switch Wiring diagram
This page shows the only wiring diagram for the component.clutch switch, which is found in the car Volvo C70 II (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram clutch switch (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRN/ORG WIRE
BUMPER COMPARTMENT DOOR LOCK ANTENNA (BEHIND CENTER OF REAR BUMPER)
CABIN 1 REAR DOOR LOCK ANTENNA (BEHIND REAR SEAT)
CABIN 2 DOOR LOCK ANTENNA (UNDER CENTER CONSOLE)
CABIN 3 DOOR LOCK ANTENNA (UNDER CENTER CONSOLE)
CLUTCH SWITCH
DRIVER DOOR CONTACT LOCKING
DRIVER DOOR LOCK MODULE
DRIVER'S DOOR LOCK UNIT (AT REAR OF LEFT FRONT DOOR)
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
GRY/WHT WIRE
KEYLESS VEHICLE MODULE (UNDER DRIVER'S SEAT)
ORG/WHT WIRE
PASSENGER'S DOOR LOCK UNIT (AT REAR OF RIGHT FRONT DOOR)
RELEASE MOTOR
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/VIO WIRE
Go to component -> Keyless entry circuit (2 of 2) -> CLUTCH SWITCH
