Volvo C40 I (2021-2024) Automatic a/c circuit

94/403 94/404 94/409 94/414 94/505 94/701 BLK/WHT WIRE BLK/YEL WIRE BLU/GRY WIRE BRN WIRE BRN/WHT WIRE CENTER CONSOLE SWITCH MODULE (CCSM) CLIMATE CONTROL MODULE (CCM) COMPUTER DATA LINES SYSTEM FRONT BLOWER MODULE FRONT BLOWER MOTOR GRN WIRE HUMIDITY SENSOR LEFT DASHBOARD AIR DUCT TEMPERATURE SENSOR LEFT SEAT MODULE (SML) RED WIRE RED/ORG WIRE RED/WHT WIRE RIGHT DASHBOARD AIR DUCT TEMPERATURE SENSOR RIGHT END OF DASH) SEAT HEATING REAR MODULE (SHRM) SEATS SYSTEM VIO WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE YEL WIRE YEL/BLK WIRE

94/301 94/303 94/404 94/414 AIR QUALITY SENSOR (AQS) BLK WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/GRY WIRE BLU/YEL WIRE BRN WIRE BRN/GRY WIRE CENTRAL ELECTRONIC MODULE (CEM) CENTRAL FUSE BOX COMPARTMENT COOLANT PUMP COMPUTER DATA LINES SYSTEM ENGINE CONTROLS SYSTEM FUSE 17 FUSE 19 FUSE 3 FUSE 4 FUSE 52 GRN/BRN WIRE HOT AT ALL TIMES HOT W/ COMFORT RELAY ENERGIZED RED/BRN WIRE RED/ORG WIRE RED/WHT WIRE RED/YEL WIRE STEERING WHEEL MODULE (SWM) SUN SENSOR VIO/WHT WIRE WHT/GRN WIRE YEL/VIO WIRE

BLK WIRE BLK/ORG WIRE BRN WIRE BRN/PNK WIRE CABIN HEAT EXCHANGER TEMPERATURE SENSOR CLIMATE CONTROL MODULE (CCM) DEFROSTER DAMPER MOTOR ELECTRIC DRIVETRAIN COOLANT TEMPERATURE SENSOR EVAPORATOR TEMPERATURE SENSOR GRN/BRN WIRE GRN/GRY WIRE GRN/ORG WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE LEFT FRONT FLOOR AIR DUCT TEMPERATURE SENSOR LEFT TEMPERATURE CONTROL DAMPER MOTOR RECIRCULATION DAMPER MOTOR RED WIRE RED/BRN WIRE RIGHT FRONT FLOOR AIR DUCT TEMPERATURE SENSOR RIGHT SIDE CLIMATE UNIT AIR DISTRIBUTION DAMPER MOTOR RIGHT TEMPERATURE CONTROL DAMPER MOTOR SOLID STATE VIO WIRE VIO/ORG WIRE VIO/RED WIRE VIO/WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL/ORG WIRE YEL/VIO WIRE

94/301 94/303 94/305 94/514 BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE EFCM RELAY ENGINE CONTROLS ENGINE FUSE BOX FUSE 26 FUSE 46 FUSE 47 FUSE 49 FUSE 5 FUSE 50 FUSE 6 GRN WIRE GROUND HIGH VOLTAGE BATTERY (COMPLETE) HIGH VOLTAGE BATTERY COOLANT FLUID PUMP HIGH VOLTAGE COOLANT HEATER A (HVHA) HOT AT ALL TIMES HOT W/ ENGINE SYSTEM RELAY ENERGIZED HOT W/ HFF RELAY ENERGIZED INVERTER HIGH VOLTAGE FRONT AXLE (IHFA) NCA WIRE ORG/ WIRE RED WIRE SYSTEM VIO/ORG WIRE VIO/WHT WIRE YEL/BRN WIRE YEL/ORG WIRE

94/301 AIR CONDITIONING COMPRESSOR MODULE A (ACCA) BLK WIRE BLK/GRN WIRE BLU WIRE BLU/BRN WIRE BLU/WHT WIRE CLIMATE COOLANT VALVE MODULE (CCVM) ELECTRIC DRIVETRAIN COOLANT PUMP ELECTRICAL EXPANSION VALVE (EXV) ENGINE CONTROLS SYSTEM GRN WIRE GROUND NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/GRY WIRE ORG/YEL WIRE OUTSIDE HEAT EXCHANGER VALVE (OHXV) RED WIRE VIO/ORG WIRE VIO/WHT WIRE WATER COOLED CONDENSER VALVE BLOCK YEL/BRN WIRE YEL/ORG WIRE

94/301 A/C COOLANT TEMPERATURE SENSOR BATTERY HEAT EXCHANGER SENSOR BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE COMPRESSOR INLET SENSOR COMPRESSOR OUTLET SENSOR COMPUTER DATA LINES SYSTEM ENGINE CONTROL MODULE (ECM) GRN/GRY WIRE GRN/VIO WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE HIGH VOLTAGE BATTERY COOLING EXTERNAL TEMPERATURE SENSOR NCA WIRE OHX OUTLET SENSOR ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/GRY WIRE ORG/WHT WIRE ORG/YEL WIRE PNK WIRE RADIATOR COOLING FAN RED WIRE VIO/BLK WIRE VIO/BRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/RED WIRE WATER COOLED CONDENSER OUTLET SENSOR YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE
