Volvo C40 I (2021-2024) vehicle gateway module Wiring diagram
This page shows the only wiring diagram for the component.vehicle gateway module, which is found in the car Volvo C40 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vehicle gateway module (1 of 1)
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BLU/ORG WIRE
BRN/GRY WIRE
CENTRAL ELECTRONIC MODULE (CEM)
CENTRAL FUSE BOX
COMPUTER DATA LINES SYSTEM
FUSE 2
FUSE 3
FUSE 41
FUSE 42
FUSE 63
FUSE 71
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION EXTENDED RELAY ENERGIZED
LEFT RESTRAINT MODULE (RML) (BASE OF LEFT "B" PILLAR)
ORG/ WIRE
RED WIRE
RED/YEL WIRE
RIGHT RESTRAINT MODULE (RMR) (BASE OF RIGHT "B" PILLAR)
VEHICLE GATEWAY MODULE
VIO WIRE
WHT WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraints circuit (2 of 4) -> VEHICLE GATEWAY MODULE
