Volvo C40 I (2021-2024) tcam backup battery Wiring diagram
This page shows the only wiring diagram for the component.tcam backup battery, which is found in the car Volvo C40 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tcam backup battery (1 of 1)
94/403
94/409
BLK/WHT WIRE
BRN/RED WIRE
CENTRAL ELECTRONIC MODULE (CEM)
CENTRAL FUSE BOX
COMPUTER DATA LINES SYSTEM
FUSE 27
GRN WIRE
GRN/BRN WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INFOTAINMENT HEAD UNIT (IHU)
NCA WIRE
OVERHEAD CONSOLE (OHC)
RED/BLU WIRE
TCAM BACKUP BATTERY
TELEMATICS, CONNECTIVITY ANTENNA MODULE (TCAM)
VIO/GRN WIRE
VIO/WHT WIRE
VOLVO ON CALL BACKUP SPEAKER
WHT WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Telematics circuit -> TCAM BACKUP BATTERY
