Volvo C40 I (2021-2024) right rear seat backrest heater Wiring diagram
This page shows the only wiring diagram for the component.right rear seat backrest heater, which is found in the car Volvo C40 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear seat backrest heater (1 of 1)
94/414
94/5028
94/5029
94/505
94/561
94/562
94/563
94/564
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/WHT WIRE
CENTRAL FUSE BOX
CLIMATE CONTROL MODULE (CCM)
COMPUTER DATA LINES SYSTEM
FUSE 14
HOT AT ALL TIMES
LEFT REAR SEAT BACKREST HEATER
LEFT REAR SEAT CUSHION HEATER
LEFT SEAT MODULE (SML)
REAR SEAT HEATING MODULE (SHRM)
RED WIRE
RIGHT REAR SEAT BACKREST HEATER
RIGHT REAR SEAT CUSHION HEATER
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
Go to component -> Rear heated seats circuit -> RIGHT REAR SEAT BACKREST HEATER
