Volvo C40 I (2021-2024) right power operated tailgate motor Wiring diagram
This page shows the only wiring diagram for the component.right power operated tailgate motor, which is found in the car Volvo C40 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right power operated tailgate motor (1 of 1)
94/409
94/414
94/541
94/601-1
94/604
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN/GRY WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CENTRAL ELECTRONIC MODULE (CEM)
CENTRAL FUSE BOX
COMPUTER DATA LINES SYSTEM
FOOT MOVEMENT DETECTION MODULE (FMDM)
FUSE 2
FUSE 29
FUSE 5
FUSE 83
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ BATTERY SAVER RELAY ENERGIZED
INSTRUMENT PANEL SWITCH MODULE
LEFT POWER OPERATED TAILGATE MOTOR
ORG/ WIRE
ORG/BLK WIRE
ORG/GRY WIRE
POWER OPERATED TAILGATE CLOSING UNIT
POWER OPERATED TAILGATE MODULE (POT)
POWER OPERATED TAILGATE SWITCH
RED WIRE
RIGHT POWER OPERATED TAILGATE MOTOR
TRUNK LID LOCK
VIO/BLK WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT/GRN WIRE
Go to component -> Trunk/tailgate & fuel door release circuit -> RIGHT POWER OPERATED TAILGATE MOTOR
