Volvo C40 I (2021-2024) outlet high voltage battery coolant temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.outlet high voltage battery coolant temperature sensor, which is found in the car Volvo C40 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram outlet high voltage battery coolant temperature sensor (1 of 1)
BATTERY ENERGY CONTROL MODULE (BECM)
BLK/BRN WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
GRY WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HVIL
INLET HIGH VOLTAGE BATTERY COOLANT TEMPERATURE SENSOR
MANUAL SERVICE DISCONNECTOR (MSD)
NCA WIRE
NTC-IN
NTC-OUT
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/DK BLU WIRE
ORG/DK GRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/RED WIRE
ORG/VIO WIRE
ORG/YEL WIRE
OUTLET HIGH VOLTAGE BATTERY COOLANT TEMPERATURE SENSOR
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance electric (6 of 18) -> OUTLET HIGH VOLTAGE BATTERY COOLANT TEMPERATURE SENSOR
