Volvo C40 I (2021-2024) (lower left rear of engine compt, Wiring diagram
This page shows the only wiring diagram for the component.(lower left rear of engine compt,, which is found in the car Volvo C40 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (lower left rear of engine compt, (1 of 1)
94/303
94/330
94/350
94/433
94/514
BLK/YEL WIRE
BRN/ORG WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONIC GEAR SELECTOR MODULE (EGSM)
ENGINE FUSE BOX
FUSE 2
FUSE 39
GRN WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
LEFT REAR PARKING BRAKE CALIPER MOTOR
MAIN BATTERY FUSE BOX
RED WIRE
RED/WHT WIRE
RIGHT REAR PARKING BRAKE CALIPER MOTOR
VIO/ORG WIRE
WHT WIRE
YEL/ORG WIRE
Go to component -> Electric parking brake circuit -> (LOWER LEFT REAR OF ENGINE COMPT,
